DeWALT DWS709
Overview
Dewalt's DWS709 15 Amps 12 in. Slide Compound Miter Saw is compact and lightweight design allowing for easy transportation and storage. Dual horizontal steel rails with innovative clamping mechanism and linear ball bearings deliver an accurate, durable and compact saw. Precise miter system and machined base fence support optimize durability and cutting accuracy.
Features
- Powerful 15 amp, 3,800 RPM motor delivers extended power and durability
- Tall sliding fences support crown molding up to 5-1/2 in. nested and base molding up to 4-1/2 in. vertically against the fence while easily sliding out of the way for bevel cuts
- Exclusive Back Fence design cuts up to 2 in. x 14 in. dimensional lumber at 90 degrees and 2 in. x 10 in. at 45 degrees
- Adjustable stainless steel miter detent plate with 10 positive stops improves productivity and ensures cutting accuracy
- Miters 60 degrees to the right and 50 degrees to the left providing increased capacity
- Oversized bevel scale makes bevel angle adjustments accurate and easy
What's in The Box
- 15 Amp 12 in. Slide Compound Miter Saw - DWS709
- Carbide Blade
- Blade Wrench
- Dust Bag
- Material Clamp
- Owner's Manual
Warranty
- 3-Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
| Specifications | |
|---|---|
| Model | DWS709 |
| Brand | Dewalt |
| Voltage | 120-Volt |
| Aperage | 15 |
| Arbor Size | 5/8-Inch - 1-Inch |
| Bevel | Dual |
| Blade Diameter | 12-Inch |
| Blade Speed RPM | 3,800 |
| Cutting Capacity (0 Miter/0 Bevel) | 2 x 14-Inch |
| Cutting Capacity (0 Miter/45 Bevel Left) | 2 x 10-Inch |
| Cutting Capacity ((0 Miter/45 Bevel Right) | 2 x 10-Inch |
| Cutting Capacity (45 Miter Left/0 Bevel) | 4.5 x 6.8-Inch |
| Cutting Capacity (45 Miter Right/0 Bevel) | 4.5 x 6.8-Inch |
| Max. Miter Angle (Left) | 50 Degrees |
| Max. Miter Angle (Right) | 60 Degrees |
| Positive Miter Detents | 10 |
| Slide System | Dual Rail |
